ZBJ-12A paper cup machine is a high gram paper cup shaping machine,it runs a whole procedure of the paper feeding,gluing,oiling,bottom punching,heating,rolling,rounding,and tripping.It is an automatic machine you can control the speed according to the production!For a better cup body and bottom connection,it used ultrasonic and hot air for heating,the heating phase into three steps,Advanced technology allowed facility more safty both on itself and operator.
It is an ideal equipment to make the paper cups for hot drink,cold drink, and ice cream paper cups.
Main Technical Parameters
|
Voltage
|
380V 50HZ 3-phase plug and 4 piece line
|
|
Power
|
4.8KW
|
|
Heating system
|
Ultrasonic and hot air heating
|
|
Production range
|
6oz—24oz（180ml—700ml,mould replacement is available）
|
|
Paper request
|
150gsm—450gsm（single&doulble PE coated paper are accepted）
|
|
Speed
|
40-50pcs/min
|
|
Dimension
|
2700mmX1500mmX1500mm
|
|
Divided box
|
125’
|
|
Weight
|
1.7Ton
|
|
Remark
|
We can make the machine according to customer’s request
|
Feature:
1. It is an intellectualization equipment,easy to operate(one person).It has the whole production line from paper fan to ready paper cup!
2. It adopt the best ultrasonic in China,has the steady performance
3. It used 125’ divided box,has the long life usage than normal machine
4. It used the Danfoss’ transducer(from Danmark),can control the speed by operator
5. Photoelectricity tracking,,automatic failure alarm,inspecting make the production more efficient
6. Stainless steel panel and the metal painting,make the machine in good shape.
